Our seamless precision pipe is the carbon, alloy steel pipe with high precision sizes. It has been made through cold drawn (cold rolling) processes.
It is designed with several advantages:
IATF16949 Automotive Quality System Certification
Better malleability
Inside and outside surface no oxide coating;
High pressure, no leaking;
Strict less tolerance;
Surface smooth;
No reformation in cold bending, no cracks during flaring test, and flattening test.
Out diameter: 10-90mm, wall thickness: 1-20mm
| EUROPEAN STANDARDS | EN 10305-1, |
| DIN 2391, | |
| BS 6323/4, | |
| NF A 49-310, NF A 49-312, | |
| UNI 7945, | |
| STN/ČSN 42 6711, | |
| STN/ČSN 42 6712, | |
| PN-H 74240, PN-H 74220 | |
| RUSSIAN STANDARDS | GOST 8734, 9567, 12132 |
| AMERICAN STANDARDS | ASTM A450 a A519 |
| JAPANESE STANDARDS | JIS G3445 |
Steel grades for standard precision tubes
| EN 10305-1 | E215, E235, E255, E355, E410, 26Mn5, 26Mo2, C35E, C45E, 25CrMo4, 42CrMo4, 25CrMo4 |
| ASTM A519,ASTM A106, ASTM A500, ASME SA500 | 1010,1020,1026,1035,1045,1050,5120 ,5140,4120,4130,4135,4140,1041M |
| JIS 3441/JIS 3444/JIS 3445/JIS G4053/JIS G3472/JIS G4051 | STKM11A,STKM12A,STKM12B,STKM12C, STKM13A,STKM13B,SCr420,SCr440,SCM415, SCM420,SCM432/SCRRM3,SCM4,STAM 290GA, STAM 390GA, S10C, S20C, S35C, S45C |
| DIN 239 | St35, St45, St52. |
| DIN17121,EN 10297-1,DIN1629,DIN2391, EN 10305-1 | C10/CK10,C22/CK22,C35/CK35,C45/CK45, CF53,ST52,20Cr4,41Cr4,15CrMo4, 1.7218, 1.7220, 1.7225, 1.7131 |
| GB/T8162,GB/T8163,GB/T3639,GB/T3087,GB/T3094 | Carbon：10#, 20#, 35#, 45#, 55#, Q235B, Q235C, Q345D, CF53, A105 |
| Alloy:16Mn(Q345B,Q355B),20Cr,40Cr, 15CrMo,20CrMo,25CrMo4, 28CrMo,30CrMo,35CrMo,42CrMo, 20CrMnTi,40MnMoV,20Mn2,,40Mn2, 37Mn5,ZF6,16MnCr5,20MnCr5,36Mn2V, 38Mn2V,20Mn2,65Mn,15Mo3 |
| Mechanical Properties DIN EN 10305-1 | |||||||||||||
| Steel Grade | Material Number | С | LC | SR | А | N | |||||||
| Rm MPa, not less | А %, not less | Rm MPa, not less | А %, not less | Rm MPa, not less | ReH MPa, not less | А %, not less | R m MPa, not less | А %, not less | Rm MPa | ReH MPa, not less | А %, not less | ||
| Е215 | 1,021 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290-430 | 215 | 30 |
| Е235 | 1,030 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340-480 | 235 | 25 |
| Е255 | 1,040 | 580 | 5 | 520 | 8 | 520 | 375 | 12 | 390 | 21 | 440 - 570 | 255 | 21 |
| Е355 | 1,058 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490-630 | 355 | 22 |
| Е410 | 1,050 | 750 | 4 | 620 | 8 | 690 | 590 | 12 | 520 | 22 | 550 - 700 | 410 | 22 |
| 26Мп5 | 1,116 | 700 | 4 | 650 | 7 | — | — | — | — | — | — | — | — |
| С35Е | 1,118 | 590 | 5 | 540 | 7 | — | — | — | 440 | 22 | >460 | 280 | 21 |
| С45Е | 1,119 | 720 | 4 | 670 | 6 | — | — | — | 510 | 20 | >540 | 340 | 18 |
| 26Мо2 | 1,541 | 720 | 4 | 670 | 6 | — | — | — | — | — | — | — | — |
| 25СгМо4 | 1,721 | 720 | 4 | 670 | 6 | — | — | — | — | — | — | — | — |
| 42СгМо4 | 1,722 | 720 | 4 | 670 | 6 | — | — | — | — | — | — | — | — |
| 10S10 | 1,071 | 510 | 8 | — | — | 440 | 370 | 16 | — | — | 360 - 500 | 240 | 25 |
| 15S10 | 1,071 | 550 | 7 | — | — | 490 | 415 | 14 | — | — | 380 - 540 | 260 | 22 |
| 18S10 | 1,071 | 650 | 6 | — | — | 600 | 520 | 12 | — | — | 520 - 650 | 360 | 22 |
| 37S10 | 1,071 | 720 | 4 | — | — | 700 | 630 | 12 | — | — | 650 - 720 | 420 | 16 |
Delivery condition and precision tubes surface
+C Cold drawn / hard. After the last cold forming no heat treatment.
+LCCold drawn / soft. After the last heat treatment follows the cold drawing there is a light finishing pass.
+SR Cold drawn and stress relieved annealed. After the final cold drawing process the tubes are stress relieved annealed in a controlled atmosphere.
+A Annealed. After the last cold drawing process the tubes are annealed in a controlled atmosphere.
+N Normalized. After the last cold drawing process the tubes are annealed in a controlled atmosphere.
Seamless Pipe Application
Motorcycle shock absorber
Automobile Parts
Shock absorber
Track rod lever
Steel pipe for pulley
Automotive bushing
Agriculture and construction machinery
